제품 상세 정보:
|
| 재료: | AC 전압 안전성 세라믹 | 패키지 형태: | 홀, 크기를 통하여 |
|---|---|---|---|
| 온도 특성: | Y5U | 전기 용량: | 470PF |
| 정격 전압 :: | 400VAC | 작동 온도: | -25 ~125C |
| 전기 용량 허용한도: | ± 10% | 인출선 사이 거리 (밀리미터): | 10 |
| 하이 라이트: | 안정적 470 피코파라드 세라믹 콘덴서,방수 470 피코파라드 세라믹 콘덴서,다중기능 AC 안전성 축전기 |
||
AC 전압 안전성 세라믹 웨이퍼 축전기 Y1 -471K 400V Y5U
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
안전 기준 Y1 축전기 전체 시리즈 품질 규격
| 형 규격 설명 | 폭 | 두께 | 핀 피치 | 리드 | 전압 | 능력 | 재료 | 허용한도 |
| Y1-472M-Y5V | φ11.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 4700pF | Y5V | ±20% |
| Y1-332M-Y5V | φ10mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 3300pF | Y5V | ±20% |
| Y1-222M-Y5V | φ8.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 2200pF | Y5V | ±20% |
| Y1-152M-Y5V | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 1500pF | Y5V | ±20% |
| Y1-102M-Y5V | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 1000pF | Y5V | ±20% |
| Y1-472M-Y5U | φ13.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 4700pF | Y5U | ±20% |
| Y1-332M-Y5U | φ11.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 3300pF | Y5U | ±20% |
| Y1-222M-Y5U | φ10mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 2200pF | Y5U | ±20% |
| Y1-152M-Y5U | φ9mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 1500pF | Y5U | ±20% |
| Y1-102M-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 1000pF | Y5U | ±20% |
| Y1-821K-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 820pF | Y5U | ±10% |
| Y1-681K-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 680pF | Y5U | ±10% |
| Y1-561K-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 560pF | Y5U | ±10% |
| Y1-471K-Y5U | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 470pF | Y5U | ±10% |
| Y1-102K-Y5P | φ11.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 1000pF | Y5P | ±10% |
| Y1-821K-Y5P | φ11mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 820pF | Y5P | ±10% |
| Y1-681K-Y5P | φ9.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 680pF | Y5P | ±10% |
| Y1-561K-Y5P | φ8.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 560pF | Y5P | ±10% |
| Y1-471K-Y5P | φ8.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 470pF | Y5P | ±10% |
| Y1-331K-Y5P | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 330pF | Y5P | ±10% |
| Y1-221K-Y5P | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 220pF | Y5P | ±10% |
| Y1-151K-Y5P | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 150pF | Y5P | ±10% |
| Y1-101K-Y5P | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V[**]C | 100pF | Y5P | ±10% |
| Y1-820K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V[**]C | 82pF | Y5P | ±10% |
| Y1-680K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V[**]C | 62pF | Y5P | ±10% |
| Y1-560K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V[**]C | 56pF | Y5P | ±10% |
| Y1-470K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V[**]C | 47pF | Y5P | ±10% |
| Y1-330K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V[**]C | 33pF | Y5P | ±10% |
| Y1-220K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V[**]C | 22pF | Y5P | ±10% |
| Y1-150K-Y5P | φ6.5mm | T4mm | F10mm | L3-22mm | 400V[**]C | 15pF | Y5P | ±10% |
| Y1-100K-Y5P | φ6.5mm | T4mm | F10mm | L3-22mm | 400V[**]C | 10pF | Y5P | ±10% |
